■产品说明：

●导体使用裸软铜或镀锡软铜绞线

●半硬PVC绝缘

●芯线集合后铝箔麦拉带隔离

●裸软铜或镀锡软铜线地线

●地线置于铝箔麦拉带与编织层之间

  (或铝箔麦拉带与芯线之间)

●裸软铜或镀锡软铜线编制隔离，

  至少95%的覆盖率（或没有编织隔离）

●PVC被覆，多芯电脑线与资料传输电缆

●被覆外径可依客户要求加大

●额定温度：80℃；额定电压：300volts

●可通过UL VW-1SC 垂直耐燃测试

●参考标准：UL 758，UL 1581

■应用：

●符合国际电工标准规范EIA RS-232及CAD/CAM

  规定使用之电脑线。

■PRODUCT DESCRIPTION

●Tinned or bare stranded copper conductor.

●Color-coded SR-PVC insulation.

●Cores cabled under aluminum mylarshield.

●Tinned or bare copper drain wire.

●Drain wire laid between aluminum mylar and braid

   (or laid between mylar and core grous).

●Tinned or bare copper wire braid shield up to

   95% coverage (or no braid shield).

●PVC jacket, multi-core computer & data transmission cable.

●Standard or larger overall diameter is available.

●Rated temperature：80℃.Rated voltage：300 volts.

●Passes U L VW-1 SC vertical flame test.

●Reference standard: UL Subject 758, UL 1581

■APPLICATIONS：
