| 产品特性：低延迟网卡 | 品牌：Solarflare | 传输速率：10GB |
| 总线类型：PCI-E | 适用网络类型：低延迟网卡 | 型号：SFN6122F SFN5322F SFN6322F |
| 上市时间：2010 | 货源类别：现货 | 网络标准：以太网 |
| 传输介质：FC | 端口类型：PCI | LED指示灯：YES |
| 产品尺寸：28*12 | 产品重量：0.16 | OEM：不可OEM |
| 最快出货时间：1-3天 | 是否支持一件代发：不支持 | 发票：不提供发票 |
| 售后服务：店面三包 | 包装清单：no |
SFN6122F SFN5322F SFN6322F Solarflare低延迟网卡批发
SFN6122F SFN5122F 高性能 低延迟 万兆光纤网卡 服务器网卡批发
SFN6322F SFN5322F 高性能 低延迟 万兆光纤网卡 服务器网卡批发
SFN7122F SFN7322F 高性能 低延迟 万兆光纤网卡 服务器网卡批发
SMF10G-SR 10GBase-X SFP+ 短波 多模 万兆光纤模块批发
SFN8522 高性能 低延迟 10GB万兆光纤网卡批发
SFN8522-Plus Flareon Ultra Dual-Port 10GBE PCIe 3.0 Server I/O Adapter支持openonload批发TEL:13910098771
Solarflare Communications SFN8522-PLUS Flareon Ultra Dual-port 10gbe Server I/o Adapter With Ll Firmware Onload Licens
| Host Interface | PCI Express 3.1 x8 |
| Total Number of Ports | 2 |
| General Information | |
| Product Type | 10Gigabit Ethernet Card |
| Product Name | Flareon Ultra SFN8522 Server Adapter PLUS |
| Manufacturer Part Number | SFN8522-PLUS |
| Product Line | Flareon Ultra |
| Manufacturer | Solarflare Communications, Inc |
| Marketing Information | The PLUS variant of the Flareon Ultra SFN8522 Dual-Port 10GbE SFP+ Server I/O Adapter adds a suite of enabled software capabilities that provide out-of-the box support for ultra-low- latency Onload-accelerated sockets as well as PPS and PTP time synchronization support. The SFN8522-PLUS is capable of associating a hardware time-stamp with every incoming and outgoing Ethernet frame for application troubleshooting or performance monitoring. These features make the SFN8522-PLUS the ultra-low-latency Ethernet adapter of choice to deploy as a key component throughout Financial Trading infrastructures where two ports of 10GbE are required. CPU-Effecient Networking The Flareon Ultra SFN8522-PLUS dual-port 10GbE Ethernet SFP+ server adapter delivers faster, more effecient processing of network traffic to accelerate a wide range of applications. The SFN8522-PLUS has 8 lanes of PCIe 3.1 minimizing latency and maximizing bus throughput between the adapter and the host. Flexibility in Operation In a virtualized environment the adapter supports hyperv***r bypass via SR-IOV providing virtualized guests with near bare-metal network performance. Multiple physical functions are also available enabling the ports to be partitioned when connected to 802.1Q trunked switch ports with a logical interface per VLAN being presented to the operating system. Ports on the same adapter or across multiple adapters may be bonded for redundant operation. This redundancy support also extends to Onload? with accelerated sockets capable of running across both Active-Passive and Active-Active LACP-enabled links. The SFN8522-PLUS enables the following licensed features enabled: Ultra-Low Latency The Flareon Ultra SFN8522-PLUS offers fast and effecient hardware that optimizes packet how to and from the user application. The SFN8522-PLUS unlocks unrivaled sub-microsecond latency both at Layer 2 and TCP and UDP via Onload. Onload Onload is Solarfare&＃39;s industry&＃39;s leading fully RFC-compliant kernel-bypass user-space TCP/ IP stack. Unrivaled application-to-application TCP and UDP latency is available with no modifcation to the applications being accelerated. Applications may communicate via Onload to any other RFC-compliant TCP/IP stack with seamless interoperability. Precision Time The SFN8522 is equipped with a Stratum 3 oscillator providing class-leading clock stability. The SFN8522-PLUS enables the use of sfptpd, Solarfare&＃39;s time synchronization daemon, which leverages the adapter&＃39;s ability to apply hardware time-stamps to incoming and outgoing Ethernet frames to synchronize its oscillator either via the PTPv2 protocol or a combination of PPS and NTP. Sfptpd also enables the Linux real-time clock to be synchronized to the external timing reference via the adapter clock. Any time-stamps obtained from either packet events or via the Linux time API may now be correlated directly with the external timing source. These features allow users to implement event traceability that exceeds the MIFID II requirements. |
| Packaged Quantity | 1 |
| Brand Name | Solarflare |
| Physical Characteristics | |
| Height | 2.7" |
| Width | 5.3" |
| Form Factor | Plug-in Module |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Network & Communication | |
| Network Technology | 10GBase-X |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Title | |
| Product Title | Solarflare Flareon Ultra Sfn8522 Server Adapter Plus - Pci Express 3.1 X8 - 2 Port[s] - Optical Fiber (SFN8522PLUS) |
Solarflare SFN8522低延迟网卡Solarflare SMF10G-SR 10GB万兆短波多模光纤模块SFN8522-Plus Flareon Ultra Dual-Port 10GBE PCIe 3.0 Server I/O Adapter支持openonload批发SFN6122F SFN5322F SFN6322F SFN7002F SFN7122F SFN7322F SFN5122F SFN5152 SFN7124F SFN7004F SFN4112F SFN5161T SFN7142Q SFN5162F等Solarflare低延迟网卡批发
Solarflare SOLR-SFM10G-SR 10GBASE-SR SFP+ Transceiver SFP+万兆多模光收发模块 短波多模万兆光纤模块批发FOR适用于SOLARFLARE SFN7122F SFN6322F SFN5162F SFN7002F SFN6122F SNF5122F SFN7322F SFN7142Q SFN5152F SFN4122F SFN5161T NF5122F等Solarflare万兆光纤网卡批发
SFN8522 SMF10G-SR SFN8522-Plus SFN6122F SFN5322F SFN6322F SFN7002F SFN7122F SFN7322F SFN5122F SFN5152 SFN7124F SFN7004F SFN4112F SFN5161T SFN7142Q SFN5162F等Solarflare低延迟网卡批发
47C9977 A522 Solarflare SFN7122F 2x10GbE SFP+ Flareon Ultra Adapter for IBM System x万兆双口网卡批发
| Part number | Feature code | Description |
| 47C9977 | A522 | Solarflare SFN7122F 2x10GbE SFP+ Flareon Ultra Adapter for IBM System x |
Table 2. Supported SFP+ transceivers
| Part number | Feature code | Description |
| Optical Transceivers | ||
| 49Y4216 | 0069 | Brocade 10Gb SFP+ SR Optical Transceiver |
| 46C3447 | 5053 | IBM SFP+ SR Transceiver (10Gb) |
| 49Y4218 | 0064 | QLogic 10Gb SFP+ SR Optical Transceiver |
| Part number | Feature code | Description |
| Active DAC/Twinax cables | ||
| 95Y0323 | A25A | 1m IBM Active DAC SFP+ Cable |
| 95Y0326 | A25B | 3m IBM Active DAC SFP+ Cable |
| 95Y0329 | A25C | 5m IBM Active DAC SFP+ Cable |
| Passive DAC/Twinax cables | ||
| 00D6288 | A3RG | .5m IBM Passive DAC SFP+ Cable |
| 90Y9427 | A1PH | 1m IBM Passive DAC SFP+ Cable |
| 00AY764 | A51N | 1.5m IBM Passive DAC SFP+ Cable |
| 00AY765 | A51P | 2m IBM Passive DAC SFP+ Cable |
| 90Y9430 | A1PJ | 3m IBM Passive DAC SFP+ Cable |
| 90Y9433 | A1PK | 5m IBM Passive DAC SFP+ Cable |
Technical specifications
The SFN7122F adapter has the following specifications:
Based on the Solarflare Solarstorm SFC9120 controller.
Two 10GbE SFP+ ports with support for optical SFP+ modules and Direct Attach Copper (DAC) cables.
Full line-rate performance across all ports.
Very low latency:Low-profile form factor.
SFN7122F without OpenOnload: 6.3 μs (TCP) and 5.4 μs (UDP)
SFN7122F with OpenOnload: 1.8 μs (TCP) and 1.7 μs (UDP)
PCI Express 3.0 x8 host interface for full, 40 Gbps bidirectional bandwidth.
Jumbo Frames support (9216 byte frames).
IEEE 802.1q VLAN support provides enhanced network management and efficiency.
Support for VMware NetQueue and Microsoft VMQ improves network performance in virtualized environments.
Support for NIC teaming.
IEEE 802.3x flow control support.
Receive Side Scaling (RSS) with 2048 virtual channels (1024 per port) distributes IPv4/IPv6 loads across processor cores.
Accelerated Receive Flow Steering (RFS) intelligently aligns I/O processing with application processing to a single processor core by using on-chip advanced packet filtering.
TCP, IP, and UDP checksum offload.
IP flow filtering enables the hardware to steer packets that are based on IP, TCP, and UDP header contents to a virtual channel.
MAC address filtering enables the hardware to steer packets that are based on the MAC address to a virtual channel.
Advanced Packet Filtering: 4096 multicast filters, 4096 VLANs/port, adaptive TCP/UDP/IP, MAC, VLAN, RSS, and RFS filtering, and Accelerated Receive Flow Steering (RFS).
Message Signaled Interrupts (MSI) and MSI-X support maximizes server processing performance by reducing processing impact and lowering interrupt latency.
Supports Large Send Offload (LSO), Giant Send offload (GSO) TCP Segmentation Offload (TSO), and Large Receive Offload (LRO) for improved adapter performance and reduced processor utilization.
Supports Intel QuickData, which uses host DMA engines to accelerate I/O.
Supports SR-IOV.
Supports iSCSI boot and PXE boot.
Supports SNMP and ACPI 3.0.
Power consumption (typical): 5.9 W.
The adapter has the following restrictions:
No UEFI support. Adapter boot by using legacy BIOS only.
No support for Wake on LAN (WoL).
No support for Virtual Fabric.
No support for Energy Efficient Ethernet (EEE).
No support for iSCSI offload.
No support for Ethernet Virtual Bridge (EVB).
No support for Converged Enhanced Ethernet (CEE).
No support for TCP Offload Engine (TOE).
