RSF为海德汉子公司中高端品牌，质量、精度均有***。目前有式光栅尺支持西门子、松下、三菱串口。定位精度2um、分辨率可达50纳米，安装体积小，货期快、价格优惠。欢迎自动化***来咨询订购

Interface EnDat 2.2 Mitsubishi high speed interface Panasonic serial interface

Version EnDat 2.2   Mit03-4 Mit02-2  Pana01

Model MC 15 MC 15 M MC 15 P

Measuring step 0.1 ?m (100 nm)

0.05 ?m (50 nm)

Calculation time tcal

Clock frequency

≤?5 ?s

≤?16 MHz--

Traversing speed ≤?600 m/min

Interpolation error

Electrical connection Cable, 1 m or 3 m with M12-connector 8-pin or D-sub connector 15-pin

Cable length ≤?100 m ≤?30 m ≤?50 m

Voltage supply DC 3.6 V to 14 V

Power consumption max. at 3.6 V: ≤?800 mW

at 14 V: ≤?900 mW

at 3.6 V: ≤?950 mW

at 14 V: ≤?1050 mW

Current consumtion typ. at 5 V: 80 mA (without load) at 5 V: 100 mA (without load)

Vibration 55 Hz to 2000 Hz

Shock 6 ms

≤ 500 m/s2 (EN 60 068-2-6)

≤ 1000 m/s2 (EN 60 068-2-27)

Operating temperature -10?°C to 50?°C

Weight Scanning head

 Connecting cable

 Connector

≤?18 g (without cable)

20 g/m

M12-connector: 15 g; D-sub connector: 28 g
