二手三丰MF-B3017大量程工具显微镜***销售

三丰工具显微镜

MitutoyoPrecision Measuring Microscope（Made in Japan）

三丰精密测量工业显微镜

Model型号：MF-B3017

Specifications技术规格:

- Measuring Range测量范围                        : 300(X)×170(Y)mm

- Measuring Accuracy测量精度(20°C)        : (2.5+0.02L)μm (L = measuring length测量长度mm)

- Digital counter测量显示                           : X, Y,Z 3axis二轴

- Digital counter resolution分辨率                :0.001mm /0.0005mm/0.0001mmswitchable可转换

- Image观察像                                           : Erect image立体像.

- Objective物镜                                          : 3X（标准件No. 375-037）

- Focusing Range对焦行程(Z轴)          : 200mm

- Focusing method对焦方式                        : Manual focusing手动(粗调,微调)

- Transmitted illuminator透射照明装置        : Koehler illumination with adjustable aperture

                                                                   diaphragm, 12V 50W halogen lamp

                                                                  （标准件No. 513667）

- Reflected illuminator反射照明装置            : Telecentric illumination with adjustable aperture

                                                                   diaphragm, 12V 50W halogen lamp

                                                                  （标准件No. 513667）

- Table top dimentions工作台尺寸                : 610×342mm

- Effective glass size工作台玻璃台面           : 470×240mm

- Swiveling工作台旋转                               :±5°

- Max. workpiece height被测工件高度  :220mm

- Max. workpiece weight工作台载重量:20Kg

Standard Accessories标准附件:

- Main unit主机                                                      1 set                                             - Microstage工作台                                                                   1 set

- XYdigital counter数字显示器                                1 set

- Transmitted illuminator透射照明装置                    1 set

- Reflected illuminator反射照明装置                        1 set

- halogen lamp卤素灯(12V, 50W)                             3 pcs

-3X objective物镜(No. 375-034)                            1 pc

- Machine cover防尘罩                                            1 pc

- Power cord电源线                                                1 pc

- Green filter绿色滤色片                                         1 pc

- Cross-hair reticle十字线                                        1 pc

- Reticle mount十字线安装装置                               1 pc

- User’s manual操作手册                                         1 copy

Optional Accessories选购附件:   （以上价格已包含选购配件）

1. –Binocular tube 10倍双筒式目镜(***76-303-1)                  1pc

2 含DELL电脑含SONY1/2CCD含软件                       1套
