概述

霍尼韦尔 CN51 设备具有***的多功能性，支持 Windows? 和 Android? 操作系统。搭载动力强大的 1.5 GHz 双核多引擎处理器、1 GB RAM 和 16 GB 闪存，实现了程度的未来适用性。配有 500 万像素彩色摄像头，功能更出色。

产品详细信息

旨在提供***的用户体验。CN51 移动计算机配有支持多点触控且户外可视的大屏幕，为查看应用程序留有足够的空间。

减少了滚动。提高了工作效率。还可提供更多的空间用于采集签名。

CN51 计算机采用了***的智能电池技术，能够为整个班次续航提供足够的电量，减少了更换电池的费用。

其他特点和优点包括：

• 采用高性能成像器，即使在弱光环境下也能快速准确地扫描条码。

• 具有***的运动容差，可避免扫描密集型应用中代价高昂的延迟和用户挫败感。

• 500 万像素彩色摄像头与霍尼韦尔***的图像处理技术相结合，拥有识读条码之外的***功能。

• 移动文档成像 (MDI) 和远程存储采集 (RDC) 可以快速可靠地将全尺寸纸质文档和支票付款转换成电子文档。直接从采集点传输到后勤工作流程。

• CloneNGo 可提供设备预配置，可为***量的设备轻松复制主配置，实现快速启动和运行。

• 霍尼韦尔 SmartSystems? Foundation还能监控关键的子系统，以防止出现影响运行的问题。

Specifications

MECHANICAL

Dimensions
Length: 164 mm (6.45 in) with battery
Width: 74 mm (2.93 in) with battery
Depth:
Base of Unit: 28 mm (1.09 in) with battery
Top of Unit: 32 mm (1.26 in) with battery

Weight
350 g (12.3 oz) with battery

ENVIRONMENTAL

Operating Temperature
-10°C to +50°C (+14°F to +122°F)

Storage Temperature
-20°C to +70°C (-4°F to +158°F)

Charging Temperature
+5°C to +35°C (+41°F to +95°F)

Relative Humidity
Non-condensing, 95%

Rain and Dust Resistance
IP64

Drop Spec
26 drops from 1.5 m (5 ft) to concrete across the operating temperature range per MIL-STD 810G

Tumble Spec
1,000 - 0.5 m (1.6 ft) tumbles at room temperature

Electrostatic Discharge
+/- 15kV air discharge, +/- 8kV direct discharge

SYSTEM ARCHITECTURE

Microprocessor
Texas Instruments 1.5 GHz OMAP 4470 dual core, multi-engine processor architecture

Operating System
Microsoft Windows Embedded Handheld 6.5 or Android 6.0 Marshmallow with GMS

Memory and Storage
Memory: 1 GB RAM
Flash ROM: 16 GB Flash Customer-accessible microSD slot for removable memory cards up to 32 GB

Keypad
(27 Key) Numeric or (43 Key) QWERTY with backlit keypad

Display

• 10.16 cm (4.0 in), 480 x 800 pixel (WVGA) TFT-LCD display

• LCD supports 24 bpp color depth

• LED backlight

• Ambient light sensor

• Resistive multi-touch touch panel

Power
Smart Battery Pack: 3.7V, 3920 mAh; Batteries are IEEE 1725 compliant, Li-Ion, removable, rechargeable.

Scanning Performance
Scan Engine Options:
EA30 high performance motion-tolerant 2D Imager; (up to 500 in/s) white LED illumination; red laser aimer and framer optimized for all lighting conditions. Capable of scanning all common 1D and 2D barcodes; 1D as small as 4 mils; 2D as small as 6.6 mils. Refer to User&＃39;s Manual for depth of field performance.

EA31 high performance motion-tolerant 2D Imager; (up to 400 in/s) white LED illumination. Capable of scanning all common 1D and 2D bar codes; 1D as small as 4 mils; 2D as small as 6.6 mils. Refer to User&＃39;s Manual for depth of field performance.

Integrated Camera Option: 5 Megapixel auto focus color camera with LED flash

Accessories
Supports all CN50 charging and docking accessories as well as FlexDock modular docking system, vehicle dock, vehicle holder, snap on adaptors, removable scan handle, and magnetic stripe reader.

COMMUNICATIONS INTERFACE

Standard Communications:
USB – High Speed 2.0 Host, USB – High Speed 2.0 Client
Wireless:
Wireless LAN: IEEE?802.11 a/b/g/n on devices without Wireless WAN radio; IEEE?802.11 b/g/n on cellular devices
Security: WiFi Certified for WPA and WPA2, WAPI Certified
Authentication: 802.1x
Cisco Compatibility: CCXv4
Encryption: WEP (64 or 128 bit), AES, TKIP

Wireless PAN: Integrated Bluetooth? Power Class 1.5 Version 4 BLE

Global Positioning System (with WAN Radio option) 12 channel Integrated GPS; Network independent autonomous mode; supports assisted operation via XTRA?, CP E911

• GPS dedicated AT commands

• Protocol: NMEA-0183 V2.3

• Tracking Sensitivity: better than -158 dBm

• GLONASS support

Integrated Radios
Wireless WAN Options
UMTS / HSPA+ (Voice & Data); Worldwide except Americas, Australia and New Zealand
UMTS/HSPA Frequencies: 900, 2100 MHz
Max Speeds (Network Dependent): Uplink – 5.76 Mbps Downlink – 14.4 Mbps
GSM/GPRS/EDGE Frequencies: 900, 1800 MHz
Max Speeds (Network Dependent): Uplink – 384 Kbps Downlink – 384 Kbps

Flexible Network? (Voice & Data); Americas, Australia and New Zealand (Can be switched between the UMTS and CDMA radio networks)
UMTS/HSPA+
UMTS Frequencies: 800, 850, 900, 1900, 2100 MHz GSM/GPRS/EDGE Frequencies: 850, 900, 1800, 1900 MHz
Max Speeds (Network Dependent): Uplink – 5.76 Mbps Downlink – 14.4 Mbps
CDMA/EV-DO Rev A
Dual Band CDMA2000 Bands: BC0 & BC1 (800/1900 MHz) Max Speeds (Network Dependent): Uplink – 1.8 Mbps Downlink – 3.1 Mbps
