宁波 压缩机转子组装设备压缩机转子组装设备定制非标自动化公司 天津爱迪自动化公司是一家工业电气自动化和机械自动化设备的制造厂家，自成立以来秉承合理、挑战、 ***的经营理念，致力于客户成功的企业理念，不断自主创新，开发各类自动化设备。 油箱装配站 可以同时生产CHB021，CHB027 CN5 和 CHB027 CN6 油箱 1.摸屏上要有不同产品及程序的切换按钮 Touch screen to have different products and procedures of the switch button 2.操作屏应可以通过 TI 网络实现远程控制的功能 每台设备具有以太网络 Operating screen should be able to achieve remote control functions through the TI network Each equipment has an Ethernet network 3.要有设备功能预设置页面，信息记录等 The equipment must have the function to set up the page, the information record and etc. 4. 预设界面完成设置后要有总体展示页面显示设备所选用的工作单元 After the completion of the default interface settings, there should be an overall display of the page to display the work unit selection 5. 工艺参数的存储和展示 1）HMI 上要有油箱条码，油泵条码，客户条码，加油管条码，空，满位 电阻，油泵电流，拧泵扭力，角度，试漏时间，压力等工艺参数。 2）组装参数要每 24 小时生成一个文件自动存储到服务器上 3）存储的组装站信息包括参数列表中的所有内容 4）在操作屏幕上可以按照项目名称和组装日期调取对应的参数进行察看分析 Storage and display of process parameters 1) HMI to have the fuel tank bar code, oil pump bar code, customer code, refueling pipe bar code, air, full resistance, oil pump current, torque, torque, test time, pressure and other process parameters 2) assembly parameters to generate a file every 24 hours automatically stored on the server 3) the stored assembly station information includes all the contents in the parameter list 4) on the HMI can be in accordance with the project name and assembly date of the corresponding parameters for analysis 6.报警信息记录 1）报警信息要包括报警时间，报警代码，报警所发生的模块，包括引起报警的机构名称，引起报警的原因等 Alarm information record 1) The alarm information must be include the alarm time, the alarm code, the alarm module, including the name of the alarm, the cause of the alarm, etc. 7.设备参数追溯 1）设备参数进行更改时要记录更改的时间，更改参数的账号，更改内容 2）更改前后的参数要有记录 Equipment parameter tracing 1) To record the time of change, to change the account number of the parameter, to change the content of the device parameter 2) Changes before and after the parameters to be recorded 8. 触摸屏上要尽可能引入目视化理念（文字描述小于 20%） 1）各组装单元结构的显示 2）各个 i/o 点所在的模块信息 3）机构中各种信号状态 4）发生报警时可在对应机构的目视化界面直接查看到故障位置 5）界面上有控制机构运动的按钮，手动情况下可控制机构的运动 HMI display to simplify 1) Display of each assembly unit structure 2) Module information for each i/o point 3) Various signal states 4) When the alarm occurs, it can be viewed directly to the fault location in the HMI 5) The motion of the controllable mechanism in the manual case 9. 在界面的底部要有设备当前进行的状态的显示以及操作人员下一步要进行 的操作 At the bottom of the HMI, the current state of the equipment is displayed and the next operation is performed by the operator
