| 产品特性：喷雾干燥 | 加工定制：是 | 雾化型式：高速离心雾化 |
| 型号：MJ-01 | 蒸发能力：50-100kg/h /h | 品牌：OME |
| 适用物料：食品乳品 | 应用领域：食品乳品 | 干燥塔直径：0.8-2.5m |
| 进风温度：250℃ | 高度：2-6m | 是否跨境货源：否 |
蒸发能力：50-100kg/h
雾化器类型：压力雾化器、离心雾化器、气流雾化器
主要系统及装置：热风系统、卸料罐、高压泵均质机、雾化器、干燥室、内置流化床、旋风分离器、布袋除尘器、接料罐。
- Fully made in stainless steelAISl304 orAISl316L
- Water evaporating capacity from 3kg/h to SOkg/h
- Rotary atomizer, pressure nozzle, con-current nozzle
- Internal surface Ra<0.4? or mirror polished
- Single point or multiple points discharging
- Fines collected by cyclone, bag filter or wet scrubber
- Multi-stage drying technology
- Production of coarse, dustless powders
- Drying of heat sensitive and aromatic products
- Handling of sticky and hygroscopic products
- Drying of heat sensitive and aromatic products
- Drying air heated by electrical, steam or gas
- Explosion proof
- Automatic CIP system
Traditional Spray Dryer | OSM | OPM | OP7 | OP15 | OP25 | OP50 |
Nominal main process gas flow (kg/h) | 90 | 390 | 700 | 1500 | 2800 | 5300 |
Water evaooration capacity (kg/h) | 0.5-6 | 5-25 | 10-50 | 20-100 | 40-200 | 80-400 |
Tyical mean particle size (μm) | 5-70 | 10-80 | 10-110 | 20-120 | 40-130 | 70-150 |
Space requirements, LxWxH (m) | 2.0 x 2.0 x 2.3 | 4.0 x2.0 x2.7 | 5.0 x 4.0 x 6.0 | 6.0 x 4.0 x 6.5 | 10.0 x 5.0 x 9.0 | 11.0 x 6.0 x 12.0 |
Multi-stage Spray Dryer | OFM | OFD4 | OFD7 | OPD15 |
Nominal main process gas flow (kg/h) | 90 | 430 | 700 | 1500 |
Water evaooration capacity (kg/h) | 0.5-6 | 5-25 | 10-50 | 20-90 |
Tyical mean particle size (μm) | 30-200 | 50-250 | 50-250 | 50-300 |
Space requirements, LxWxH (m) | 3.0 x 2.5 x 3.0 | 6.0 x 4.0 x 5.0 | 8.0 x 4.5 x 6.5 | 9.0 x 4.0 x 7.0 |
