工控电源A5E30947477西门子工控机电源

现货现货现货

西门子代理商现货供应

公司出售西门子全新原装正品产品

发布人：康葵 （销售经理）发布

本公司签约正式的销售合同，并开具13%的增值税发-票。

外地客户统一采用快递发货,也支持上门提货，货物快递到您手时候,一定要开箱检验!如有损坏,请拒绝签收,并由快递公司返回!

在你签收后表示你对该货物没有异议!我们会给予您检测时间,并请在货物到给予确认,谢谢合作!

产品均为密封包装，外包装详见产品图片，白色标签上均有产品订货号和产地，各位买家在收到货后，请核对型号，无误后再拆包装、

本公司宗旨：本着以诚信为本，以顾客为中心.质量***·服务诚信·价格实惠.

为用户提供专业的自动化产品及服务！

相关西门子产品技术：

Description

The extremely compact SINUMERIK OP 08T operator panel front enables a distributed configuration of the operator panel front and controller.

The OP 08T operator panel front has a membrane keyboard with 79 keys (layout similar to SINUMERIK CNC editing keyboard KB 310C) as well as 2x8 horizontal and 2x8 vertical soft keys.

The distance to the operator panel fronts is determined by the maximum distance of two network nodes / access points.

The operator panel front OP 08T is connected to the PCU / NCU via the Ethernet as thin client in its own subnet (via DHCP server to PCU / NCU).

The mixed operation with an operator panel front is possible directly at the PCU.

The operator panel front is secured from the rear using special clamps supplied with the panel.

Validity

The description below applies to the OP 08T operator panel front

Order number: 6FC5203-0AF04-1BA0.

Features

Ethernet 10/100 Mbit/s

2x USB 1.1 for connecting the mouse, keyboard and USB flash drive

(1x front / 1x rear)

7.5" TFT flat screen with VGA resolution 640x480 pixels

Membrane keyboard with alphabetic, numeric, cursor, and control keypad

Softkeys / direct keys

- 2 x 8 horizontal rows of keys with softkey function

- 2 x 8 vertical rows of keys with softkey and direct key function

Shift key for switchover to the second key level (not for switching over the letters, since they are uppercase only)

Limited mounting depth

Panel cutout (W x H): 285 x 304 mm

IP65 degree of protection

Attachment: tension jacks at the rear
