床身上回转直径

Swing over bed

mm

400

横滑板上回转直径

Swing over cross slide

mm

210

工件长度

Distance between centers

mm

750/1000/1500/2000

主轴孔径范围

Spindle bore

mm

52(Optional 80)

主轴孔径锥度

Spindle bore taper

-

MT6

主轴鼻端型号

Spindle nose type

-

C6

主轴转速级数

Spindle speed steps

-

Manual 2 steps

主轴转速范围

Spindle speed range

rpm

L:100-500 H:500-1800 (Optional 90-1800 stepless)

刀架类型

Turret/tool post

-

Electric 4 position

刀具尺寸

Tool size

mm

25 x 25

X轴行程

X axis travel

mm

230

Z轴行程

Z axis travel

mm

750/1000/1500/2000

X轴快速进给速度

X axis rapid traverse

mm/min

6000

Z轴快速进给速度

Z axis rapid traverse

mm/min

8000

尾座套筒直径

Tailstock quill diameter

mm

65

尾座套筒锥度

Tailstock quill taper

-

MT4

尾座套筒行程

Tailstock quill travel

mm

130

主轴电机

Main spindle motor

kw

4

冷却泵电机

Coolant pump motor

kw

0.09

机床重量

Machine weight

Weightfor 750

kg

1700

Weightfor 1000

kg

1800

Weightfor 1500

kg

1900

Weightfor 2000

kg

2000

外形尺寸

Overall dimension

Dimension for 750

mm

2200x1650x1700

Dimension for 1000

mm

2500x1650x1700

Dimension for 1500

mm

3000x1650x1700

Dimension for 2000

mm

3500x1650x1700
