VACUUM COOLING SYSTEM FILLER

• The vacuum cooling system fillerensures that the cooling system is rapidly filled with coolant, free of air pockets and without any need for subsequent bleeding.

• It is used following repairs or for the firs fill. The machine also carries out a vacuum leak test, preventing the filling of a leaking cooling system.

• A vacuum is generated in the cooling system by means of the workshop compressed air supply (6...10 bar) and a venturi nozzle.

• Provided the vacuum remains constant, the cooling system can be rapidly filled, devoid of any air pockets; the coolant is drawn in under vacuum.

• the filling method can be used on any type of vehicle

• the coolant is devoid of any air pockets

• security of the process

• easy to use

• the filling process and vacuum leak test are completed in about five minutes

• no maintenance required

• can be used to bleed stationary heating systems

• independent from the volume of cooling system

• Also suitable for cooling systems in hybrid, EV and fuel cell vehicles.

DESCRIPTION

• Vacuum cooling system filler with rubber cone for connection to the cooling system opening

• Universally applicable due to the conical sealing rubber

• Filling method suitable for almost all vehicle types

• Easy to use

• Bubble-free filling

• Reliable and maintenance-free

• Filling incl. leak testing in about 5 minutes

• Also suitable to bleed stationary heating systems

• Suitable for cooling systems in hybrid and electric vehicles as well as vehicles with fuel cells

SCOPE OF DELIVERY

• 1 vacuum cooling system filler KVB 02, 1 venturi nozzle

• 2 suction/emptying tube PVC, each 1.50 m long

• 1 solid plastic case

产品编号：

KVB 01_BZ ( 011401_15 )

KVB 01 ( 011401_1 )

KVB 02 ( 011402_1 )

KVB 01.1 (011401_2)

KVB XL (011417_1)

KVBA 01 (011415_3)

KVBW 01_230VAC_LR (011424_1)
