R205F21424

Rexroth推出新型导轨，基本型线性导向系统BSCL,预紧分为C0(无预紧),C1(轻预紧),C2(中预紧),精度等给分为N,H,P,适合场所：通用机床，车削，磨削，铣削，雕铣机，注塑机，搬运，升降应用等机器及领域。

Rexroth滑块经济型FNS法兰型标准长，标准高R205A(标准密封加脂20，未加脂24)

15规格:

R205A19420,R205A19424,R205A19320,R205A19324,R205A19324,R205A11420,R205A11320,R205A11220,R205A11224,R205A12420,R205A12320,R205A12220,R205A12224

20规格:R205A89420,R205A89320,R205A81420,R205A81320,R205A81220,R205A81224,

R205A82420,R205A82320,R205A82220,R205A82424

25规格：R205A29420，R205A29320，R205A29324，R205A21420.R205A21320，R205A21220

R205A22420，R205A22320，R205A22220,R205A22424,R205A22324,R205A22224

30规格:R205A719420,R205A79320,R205A71420,R205A71320,R205A71220,R205A72420,

R205A72320,R205A72220,R205A72224,R205A72324,R205A72224

35规格：R205A39420，R205A39320，R205A31420，R205A31320，R205A31220，R205A32420

R205A32320，R205A32324，R205A32220.R205A32424,R205A32224

45规格:R205A49420,R205A49424,R205A41420,R205A41424,R205A41320,R205A41220,

R205A42420,R205A42320,R205A42220,R205A42424,R205A42324,R205A42224

Rexroth滑块经济型FLS法兰型加长型，标准高R205B(标准密封加脂20，未加脂24)

15规格:

R205B19420,R205B19424,R205B19320,R205B19324,R205B19324,R205B11420,R205B11320,R205B11220,R205B11224,R205B12420,R205B12320,R205B12220,R205B12224

20规格:R205B89420,R205B89320,R205B81420,R205B81320,R205B81220,R205B81224,

R205B82420,R205B82320,R205B82220,R205B82424

25规格：R205B29420，R205B29424,R205B29320，R205B29324，R205B21420.R205B21320，R205B21220R205B22420，R205B22320，R205B22220,R205B22424,R205B22324,R205B22224

30规格:R205B79420,R205B79320,R205B71420,R205B71320,R205B71220,R205B72420,

R205B72320,R205B72220,R205B72224,R205B72324,R205B72224

35规格：R205B39420，R205B39320，R205B31420，R205B31320，R205B31220，R205B32420

R205B32320，R205B32324，R205B32220.R205B32424,R205B32224

45规格:R205B49420,R205B49424,R205B41420,R205B41424,R205B41320,R205B41220,

R205B42420,R205B42320,R205B42220,R205B42424,R205B42324,R205B42224

Rexroth滑块经济型SNS窄型标准长型，标准高R205C(标准密封加脂20，未加脂24)

15规格:

R205C19420,R205C19424,R205C19320,R205C19324,R205C19324,R205C11420,R205C11320,R205C11220,R205C11224,R205C12420,R205C12320,R205C12220,R205C12224

20规格:R205C89420,R205C89320,R205C81420,R205C81320,R205C81220,R205C81224,

R205C82420,R205C82320,R205C82220,R205C82424

25规格：R205C29420，R205C29424,R205C29320，R205C29324，R205C21420.R205C21320，R205C21220R205C22420，R205C22320，R205C22220,R205C22424,R205C22324,R205C22224

30规格:R205C719420,R205C79320,R205C71420,R205C71320,R205C71220,R205C72420,

R205C72320,R205C72220,R205C72224,R205C72324,R205C72224

35规格：R205C39420，R205C39320，R205C31420，R205C31320，R205C31220，R205C32420

R205C32320，R205C32324，R205C32220.R205C32424,R205C32224

45规格:R205C49420,R205C49424,R205C41420,R205C41424,R205C41320,R205C41220,

R205C42420,R205C42320,R205C42220,R205C42424,R205C42324,R205C42224

Rexroth滑块经济型SNS窄型加长型，标准高R205D(标准密封加脂20，未加脂24)

15规格:

R205D19420,R205D19424,R205D19320,R205D19324,R205D19324,R205D11420,R205D11320,R205D11220,R205D11224,R205D12420,R205D12320,R205D12220,R205D12224

20规格:R205D89420,R205D89320,R205D81420,R205D81320,R205D81220,R205D81224,

R205D82420,R205D82320,R205D82220,R205D82424

25规格：R205D29420，R205D29424,R205D29320，R205D29324，R205D21420.R205D21320，R205D21220R205D22420，R205D22320，R205D22220,R205D22424,R205D22324,R205D22224

30规格:R205D719420,R205D79320,R205D71420,R205D71320,R205D71220,R205D72420,

R205D72320,R205D72220,R205D72224,R205D72324,R205D72224

35规格：R205D39420，R205D39320，R205D31420，R205D31320，R205D31220，R205D32420

R205D32320，R205D32324，R205D32220.R205D32424,R205D32224

45规格:R205D49420,R205D49424,R205D41420,R205D41424,R205D41320,R205D41220,

R205D42420,R205D42320,R205D42220,R205D42424,R205D42324,R205D42224

Rexroth滑块经济型SNH窄型 标长型，加高R205E(标准密封加脂20，未加脂24)

15规格:

R205E19420,R205E19424,R205E19320,R205E19324,R205E19324,R205E11420,R205E11320,R205E11220,R205E11224,R205E12420,R205E12320,R205E12220,R205E12224

20规格:R205E89420,R205E89320,R205E81420,R205E81320,R205E81220,R205E81224,

R205E82420,R205E82320,R205E82220,R205E82424

25规格：R205E29420，R205E29424,R205E29320，R205E29324，R205E21420.R205E21320，R205E21220R205E22420，R205E22320，R205E22220,R205E22424,R205E22324,R205E22224

30规格:R205E719420,R205E79320,R205E71420,R205E71320,R205E71220,R205E72420,

R205E72320,R205E72220,R205E72224,R205E72324,R205E72224

35规格：R205E39420，R205E39320，R205E31420，R205E31320，R205E31220，R205E32420

R205E32320，R205E32324，R205E32220.R205E32424,R205E32224

45规格:R205E49420,R205E49424,R205E41420,R205E41424,R205E41320,R205E41220,

R205E42420,R205E42320,R205E42220,R205E42424,R205E42324,R205E42224

Rexroth滑块经济型SNH窄型加长型，加高R205F(标准密封加脂20，未加脂24)

15规格:

R205F19420,R205F19424,R205F19320,R205F19324,R205F19324,R205F11420,R205F11320,R205F11220,R205F11224,R205F12420,R205F12320,R205F12220,R205F12224

20规格:R205F89420,R205F89320,R205F81420,R205F81320,R205F81220,R205F81224,

R205F82420,R205F82320,R205F82220,R205F82424

25规格：R205F29420，R205F29424,R205F29320，R205F29324，R205F21420.R205F21320，R205F21220R205F22420，R205F22320，R205F22220,R205F22424,R205F22324,R205F22224

30规格:R205F719420,R205F79320,R205F71420,R205F71320,R205F71220,R205F72420,

R205F72320,R205F72220,R205F72224,R205F72324,R205F72224

35规格：R205F39420，R205F39320，R205F31420，R205F31320，R205F31220，R205F32420

R205F32320，R205F32324，R205F32220.R205F32424,R205F32224

45规格:R205F49420,R205F49424,R205F41420,R205F41424,R205F41320,R205F41220,

R205F42420,R205F42320,R205F42220,R205F42424,R205F42324,R205F42224

Rexroth导轨经济型带塑料孔盖沉头孔型导轨R2055

15规格导轨:R205510431,R205510331,R205510231

20规格导轨:R205580431,R205580331,R205580231,

25规格导轨:R205520431,R205520331,R205520231,

30规格导轨:R205570431,R205570331,R205570231,

35规格导轨:R205530431,R205530331,R205530231,

45规格导轨:R205540431,R205540331,R205540231,

第三代Rexroth滚柱型滑块R18245232X,R18243232X,R18515232X,R18533232X,R18534232X

R1824滚柱型***产品系列:25.35,45,55,65规格

R18242132X,R18242122X,R18242232X,R18242222X,R18242212X,R18242322X,R182423312X,R18243132X,R182432332X,R18243222X,R18243212X,R18243322X,R18243312X,R18243392X,R18244132X,R18244232X,R18244122X,R18244222X,R18244212X,R18244312X,R18244392X,R18245132X,R18245122X,R18245232X,R18245222X,R18245212X,R18245322X,R18245312X,R18245392X,R18246132X,R18246122X,R18246232X,R18246222X,R18246212X,R18246322X,R18246312X,R18246392X

R1821滚柱型***产品系列:25.35,45,55规格

R18212132X,R18212122X,R18212232X,R18212222X,R18212212X,R18212322X,R182123312X,R18213132X,R182132332X,R18213222X,R18213212X,R18213322X,R18213312X,R18213392X,R18214132X,R18214232X,R18214122X,R18214222X,R18214212X,R18214312X,R18214392X,R18215132X,R18215122X,R18215232X,R18215222X,R18215212X,R18215322X,R18215312X,R18215392X

R1851滚柱型***产品系列:25.35,45,55,65规格

R18512132X,R18512122X,R18512232X,R18512222X,R18512212X,R18512322X,R185123312X,R18513132X,R185132332X,R18513222X,R18513212X,R18513322X,R18513312X,R18513392X,R18514132X,R18514232X,R18514122X,R18514222X,R18514212X,R18514312X,R18514392X,R18515132X,R18515122X,R18515232X,R18515222X,R18515212X,R18515322X,R18515312X,R18515392X,R18516132X,R18516122X,R18516232X,R18516222X,R18516322X,R18516312X,R18516392X

R1853滚柱型***产品系列:25.35,45,55,65规格

R18532132X,R18532122X,R18532232X,R18532222X,R18532212X,R18532322X,R185323312X,R18533132X,R185332332X,R18533222X,R18533212X,R18533322X,R18533312X,R18533392X,R18534132X,R18534232X,R18534122X,R18534222X,R18534212X,R18534312X,R18534392X,R18535132X,R18535122X,R18535232X,R18535222X,R18535212X,R18535322X,R18535312X,R18535392X,R18536132X,R18536232X,R18536122X,R18536222X,R18536322X,R18536392X

直线导轨导向系统 - 博世力士乐中国- Bosch?Rexroth?中国

直线导轨导向,滚珠导轨导向,滚柱导轨导向,滚轮导轨导向.直线导轨导向系统 Linear Motion Designer 博世力士乐提供种类众多的直线导轨导向产品。

法兰式单螺母 FEM-E-D

标准系列

安装尺寸按标准 JIS B1192,

表 5

– 带标准密封

– 加强型密封见主产品样本。

– 带轴向间隙，缩减的轴向间隙

– 预紧2%、3%、5%。

– 公差等级T3 1)、T5、T7、T9。

规格d 0 x P x D w - i (N)  部件号额定载荷速度 3)额定动载C额定静载C 0 v  (N)(米/分)

20 x 5R x 3 - 4 R1512110A0  14300 21500 30

20 x 10R x 3 - 4 R1512140A0  14100 21300 60

20 x 20R x 3.5 - 2 R1512170A0  9100 12100 120

25 x 5R x 3 - 4 R1512210A0  15900 27200 30

25 x 10R x 3 - 4 R1512240A0 15700 27000 60

32 x 5R x 3.5 - 4 R1512310A0 21600 40000 23

32 x 10R x 3.969 - 5 R1512340A0 31700 58300 47

32 x 20R x 3.969 - 2 R1512370A0 13500 21800 94

40 x 5R x 3.5 - 5 R1512410A0 29100 64100 19

40 x 10R x 6 - 4 R1512440A0 50000 86400 38

40 x 20R x 6 - 3 R1512470A0 37900 62800 75

40 x 40R x 6 - 2 R1512490A0 25500 40300 150

50 x 5R x 3.5 - 5 R1512510A0 32000 81300 15

50 x 10R x 6 - 6 R1512540A0 79700 166500 30

50 x 20R x 6.5 - 3 R1512570A0 47900 87900 60

50 x 40R x 6.5 - 2 R1512590A0 32100 55800 120

63 x 10R x 6 - 6 R1512640A0 88800 214300 24

63 x 20R x 6.5 - 3 R1512670A0 53200 112100 48

63 x 40R x 6.5 - 2 R1512690A0 36900 74300 95

80 x 10R x 6.5 - 6 R1512740A0 108400 291700 19

80 x 20R x 12.7 - 6  2) R1512770A0 262700 534200 30

1) 请向我们询问

2) 螺母80 x 20R x 12.7 - 6在丝杠螺纹长度小于等于2500 mm时可带预紧供货

3) 转速特征值d 0 · n和临界转速n cr请参阅滚珠丝杠传动系统主产品样本

法兰式双螺母 FDM-E-D

安装尺寸按标准 JIS B1192,

表 5

– 带标准密封

– 加强型密封见主产品样本。

– 带轴向间隙，缩减的轴向间隙

– 预紧 7%、10%。

– 公差等级 T3 1) 、T5、T7。

规格部件号d 0 x P x D w - i (N) (N) 额定载荷 速度 3)额定动载 C 额定静载 C 0 v  (米/分)

20 x 5R x 3 - 4 R1512110B0 14300 21500 30

25 x 5R x 3 - 4 R1512210B0 15900 27200 30

25 x 10R x 3 - 4 R1512240B0 15700 27000 60

32 x 5R x 3.5 - 4 R1512310B0 21600 40000 23

32 x 10R x 3.969 - 5 R1512340B0 31700 58300 47

40 x 5R x 3.5 - 5 R1512410B0 29100 64100 19

40 x 10R x 6 - 4 R1512440B0 50000 86400 38

40 x 20R x 6 - 3 R1512470B0 37900 62800 75

50 x 5R x 3.5 - 5 R1512510B0 32000 81300 15

50 x 10R x 6 - 4 R1512540B0 55400 109000 30

50 x 20R x 6.5 - 5 R1512570B0 75700 149700 60

63 x 10R x 6 - 4 R1512640B0 61800 140500 24

63 x 20R x 6.5 - 5 R1512670B0 83900 190300 48

80 x 10R x 6.5 - 6 R1512740B0 108400 291700 19

80 x 20R x 12.7 - 6 1) R1512770B0 262700 534200 30

2) 螺母 80 x 20R x 12.7 - 6 在丝杠螺纹长度小于等于 2500 mm 时可带预紧供货

轴承座组件 SED-L-S

浮动支承

带深沟球轴承

轴承座组件由下列零件组成：

– 钢制轴承座

– 深沟球轴承

– 挡圈

规格

d 0

轴承座组件

全套

部件号

深沟球轴承

额定载荷，径向尺寸 (mm)额定动载 C 额定静载 C 0 d D B(N) (N)

20 R159661500 5600 2530 15 32 9

25 R159662000 12800 6600 20 47 14

32 R159662500 14000 7850 25 52 15

轴承座组件 SED-F-Z

固定支承

带轴向角接触球轴承

轴承座组件由下列零件组成：

– 钢制精密轴承座

– 2 个预紧的轴向角接触球轴承

– 轴端螺母

– 端盖

– 径向轴密封

规格轴承座组件

全套

部件号

轴向角接触球轴承轴端螺母

额定动载 C 额定静载 C 0 轴向载荷 尺寸 (mm) M Ad 0 (N) (N) (N) d D B (Nm)

20 R159651500 8800 12700 5490 15 32 18 10

25 R159652000 18600 27500 12900 20 47 28 18

32 R159652500 21000 34900 15600 25 52 30 25
