深圳市科瑞芯电子有限公司为南芯的方案开发商，商品原厂原装

供应具有混合功率升压模式和处理器热监测器的同步双向降压充电器控制器，可为终端客户提供样品及技术支持！

深圳市内可送货上门，欢迎致电！

型号：SC89780

封装：QFN4X4-28

品牌：SOUTHCHIP/南芯

温馨提示：由于公司产品型号较多，如有具体需求可直接致电或QQ联系！

Descriptions

The SC89780 is a synchronous buck charger that supports buck and boost modes during forward or reverse discharging operations. It manages 1S to 4S battery charging from a wide input range from 4.5V to 24V and supports automatic system power selection with NMOS drivers on the battery and adapter sides.

The device adopts hybrid power boost architecture, allowing the battery to work with the adapter to supply the system load when it exceeds the adapter capability in turbo mode. The adapter provides the system power directly and charges the battery pack with dynamic power management to avoid over-loading. As the system power increases, the charging current will reduce to maintain the adapter current in regulation. The hybrid power boost mode will be triggered to supplement system power if the system power continuously increases.

The user can flexibly set the charging current, charging voltage, input current limit, discharge current limits, switching frequency, and other parameters flexibly through the SMBUS interface. Besides, charging and discharging current also can be set in real-time via the external ILIM pin.

The SC89780 complies with Intel IMVP8/IMVP9 specifications, including system power, input current, charging or discharging current monitoring, and processor hot indication.

The SC89780 can operate in learn and ship modes to meet the user&＃39;s demands. Full protection includes over-temperature protection, adapter, and battery over-voltage protection, input MOSFETs over-current protection, battery, inductor, and MOSFET short circuit protection.

The SC89780 is available in a 4mm x 4mm QFN-28 Package.

Features

● Wide Input Range: 4.5V to 24.5V, 30V sustainable

● Buck Battery Charger for 1 to 4 Cell Batteries

● Hybrid Power Boost Operation for Turbo Mode

● Ultra-Fast Transient Response Time of 150us to Enter Hybrid Boost Mode

● Automatic Power Source selection from Adapter or Battery with integrated NMOS Driver

● ± 0.4% Charge Voltage Accuracy with 16mV/step

● ± 2% Input Current Accuracy with 64mA/step (10mΩ)

● ± 2% Charge Current Accuracy with 64mA/step(10mΩ)

● ± 2% Discharge Current Accuracy with 512mA/step 10mΩ)

● Dynamic Power Path Management

● SMBUS Interface

● Charge Current And Discharge Current Can be Limited by An External Resistor in Real-Time

● Input Current Regulation to Avoid Overload

● Switching Frequency: 400/600/800/1000kHz

● PROCHOT Profile for Intel IMVP8/IMVP9

● Integrated Independent Comparator

● Current Monitor & System Power Monitor

● Low Adapter Standby Current for Energy Star

● Automatic End of Charge

● Learn Mode for Battery Gauge

● Ship Mode

● Protection including UVP, OVP, OCP, SCP, OTP

● QFN-28 Package

Applications

● Ultra-Books, Notebooks, Tablet PCs

● Industrial Equipment

● Equipment with Rechargeable Batteries
