HAMAMATSU滨松 EQ-99X-FC-S 激光驱动光源 (LDLS)

EQ-99X-FC-S 是一款光纤耦合 LDLS。可提供两种类型的光纤，以选择符合用途需求的波长范围。EQ-99X-FC-S 采用紧凑型灯头结构，发热更小，非常适合在狭小空间内进行实验或在设备中安装。灯头设计为通过自然对流制冷，从而消除了制冷风扇引起的振动，并确保高度稳定的光输出。

特点

• Extremely broad wavelength range：170 nm to 2500 nm

• Fiber can be selected from 2 types（UV type：190 nm to 900 mn、Broadband type：350 nm to 2500 nm）

• Long lifetime：10 000 hours

• High radiance from a small plasma

详细参数

*1 The optical fiber should be selected according to wavelength range required for the application.

*2 Optical power from the optical fiber (UVFIBERX-230) was measured with a thermopile.

*3 The configuration is different for sales to Japan. Please contact us for details.

Fiber specifications

Optical fibers can be selected with the following core diameters, lengths and connector terminations.

※ The model number of each optical fiber is determined by fiber type, core diameter, length and connector termination.

Example: UVFIBERX-230-1M-FC-SMA (UV type, fiber core diameter: 230 μm, length: 1 m, connector: FC-SMA)

* The EQ-99X-FC must use the above dedicated optical fibers.

Attempting to use any other optical fibers will cause optical fiber connector problems, damage to the lamphead and will affect performance.

*4 Although light at wavelengths shorter than 350 nm also passes through the broadband type optical fiber, the fiber transmittance within that wavelength range will drop within a short time. For applications that require UV output, we strongly recommend selecting the UV type optical fiber as they are optimized for that wavelength range.
