最小压力阀由阀体、阀芯、调节螺母、弹簧、密封元件等组成。
最小压力阀的作用：
1、最小压力阀的作用是缓冲一下，当机器在加载瞬间，我们假设排放到大气中，机器内部分离前与分离后产生的大压差将全部加在分离器上，造成对分离器芯的伤害；
2 、机器油润滑是靠机器本身的压力差进行，没有额外的油泵辅助，当机器在空载状态时，仍需一定压力维持油循环，所以进气阀门相对关闭，而最小压力阀防止压力泄漏，这样***润滑油循环。
3、最小压力阀主要起建立机组内压，促使润滑油循环、满足减荷阀的工作压力等作用。
4、另外最小压力阀也起单向阀的作用，防止机组在卸载运行时储气罐中的压缩空气倒流至空压机。

欢迎各界同仁来人来电咨询、洽谈!详细资料至公司索取。我们将以***的产品，***的价格，优质的服务与您密切合作，共谋发展！

       企业***：

        国内热线：400-6969-728

       技术咨询：021-51602627    51602681

 【进口压缩机国际亚洲配送中心】【中国空压机备品备件营销中心】

Minimum pressure valve by valve body, valve core, adjust nut, spring, sealing element, etc.

The role of the minimum pressure valve:

1, the minimum pressure valve is used to buffer, when the machine load moment, we assume that the emissions into the atmosphere, the machine internal separation of before and after the separation of large differential pressure will be added on the separator, the separator core damage;

2, watch oil lubrication depends on the pressure difference between the machine itself, no additional auxiliary pump, when the machine is in idle state, still need some pressure to maintain oil circulation, so the inlet valve is relatively closed, and the minimum pressure valve to prevent leakage, so that guarantee the oil circulation.

Unit 3, minimum pressure valve is mainly to establish internal pressure, pushing oil circulation, satisfy the load reducing valve working pressure, and so on.

4, the minimum pressure valve also ACTS as one-way valve, prevent unloading the runtime propane tanks of compressed air back to the air compressor.
