| 加工定制：是 | 品牌：双兴仪表 | 型号：UQK-01/02/03-C |
| 测量范围：8-1000mm | 电源电压：AC380V/AC220VV | 测量精度：±2mm |
| 用途：液位测量 |
UQK-01/02/03-C(B)型船用浮球液位控制器 MARINE FLOAT LEVEL CONTROLLER
◆概述 GENERAL
UQK-01/02/03-C(B)型船用浮球液位控制器适用于船舰，化工及其它工业设备中对舱柜内液位进行两位式控制和报警。
UQK-01/02/03-C(B) Type marine float level controller is widely used in ship chemical industry and other industrial instrument to control and alarm the level in tank by two position type .
◆技术参数 TECHNICAL SPECIFICATION
型 号 Model | UQK-01-C(B) | UQK-02-C(B) | UQK-03-C(B) |
安装形式 Mounting type | 侧 装 Horizontal mounting | 顶 装Top mounting | |
触点容量 Contact capacity | AC220/10A DC125V/1A | ||
开关结构 Switch type | SPDT AC:250V10A DC:125V0.6A 2xSPDT（可选Option） | ||
切换差mm Switching error mm | 8mm | 25-550mm | 8-1000mm |
介子比重 Medium gravity | ≥0.65 | ||
介子温度 Medium temp | -40～120℃ | ||
工作压力 Working pressure | ≤1.0MPa | ||
防护等级 Protection | IP66/IP68 | ||
整定方式 Regulated type | 定值不可调 Fixed value & unadjustable | 分级可调整 Grading & adjustable | 无极可调整 Continuous & adjustable |
浮球直径 Float dia D mm | Φ76 Φ60 | Φ125 Φ64 | |
防爆型式 Explosion proof type | ExdIIBT4 ExiaIICT5 | ||
电缆出口Cable exit | M20X1.5(内螺纹) | ||
法兰标准 Flange standard | GB2506-89 GB573-65 | ||
-
