| 加工定制：是 | 品牌：双兴仪表 | 型号：UHZ-511/512/515 |
| 测量范围：500-5000MM | 电源电压：DC24V | 测量精度：±10 |
| 用途：液位测量 |
UHZ-51系列船用磁性浮子液位计 MARINE MAGNETIC FLOAT TYPE LEVEL GAUGE
◆概述 GENERAL
UHZ-51系列磁性浮子液位计适用于舰船及其它工业设备中对舱柜内介质的液位(或易凝固流动性差的介质液位)进行测量和控制。
UHZ type magnetic float type level gauge can be used to measure and control level of the tank inship and other industrial
instrument.
◆技术参数 TECHNICAL SPECIFICATION
规格型号 Model | UHZ-511 | UHZ-512 | UHZ-515 |
测量范围 Measuring range | 500(至to)6000mm(可选option) | ||
测量精度 Measuring accuracy | 10mm | ||
安装形式 Mounting type | 侧装式Horizontal mounting | 顶装 Top mounting | |
介质比重 Medium gravity | ≥0.5 | ||
工作压力 Working pessure(MPa) | ≤1.0(1.6、2.5、4.0）MPa | ≤2.5MPa | |
工作温度 Working temp. | ≤350℃ |
| |
介质粘度 Medium viscosity. |
| ≤0.02pa.s | ≤0.01pa.s |
蒸汽压力 Steam pressure. |
| ≤0.8MPa |
|
接口法兰 Connection flange. | GB2506-89DN20 PN1.0 | GB2506-89 DN125 PN1.0 | |
报警开关 Alarm switch. | AC:220V 2A 保持型 Retaining type(可选Option) | ||
远传信号 Output signal. | DC24V 4-20mA (可选Option) | ||
配套阀门 Matched valve. | 1、截止阀Shut-off valve 2、自闭阀Self-close valve 3、球阀 Ball valve(可选Option) |
| |
◆外型尺寸 OUTLINE DIMENSION
◆配套阀门 SUPPORTING THE VALVE
截止阀 Shut-off valve
自闭阀 Self-close valve
球阀 Ball valve
-
￥1180.00 -
￥1250.00
-
￥600.00
