高速探测器和接收器：

The BPDV3120R balanced photodetector consists of two 75 GHz waveguide-integrated photodiodes on one single chip.As a single-balanced photodetector the configuration ensures excellent uniformity of the paired photodiodes and their integrated biasing network.Due to optimized alignment of the waveguide and photodiode design, a linear frequency response is guaranteed even at high optical powers.An integrated 50Ωtermination allows excellent matching with the electrical output signal.Tailored configurations are available, e.g. BPDV dual pair and quad sets, including fiber matching and optical connector customization.

主要特性：

◆70 GHz bandwidth guaranteed

◆Excellent uniformity of photodiodes

◆Detection of 64 Gbaud x-QAM signals

◆Integrated 50Ωtermination

◆Unique on-chip integrated bias network

◆Available as dual-pair / quad-set

◆Temperature:0 ...+75°C

◆Supply voltage:+3.3/-3.3 V

◆Transmission formats:DPSK, DP QPSK, QAM

主要应用：

◆DWDM

◆Next generation networks

◆Transmission systems of 400 Gb/s through 1 Tb/s

◆Coherent test and measurement systems

◆Research and development systems

类型：

光电探测器

Data Rate:

100 Gbps

波长：

1550nm
